The versatility of this modular t-slot aluminum profile system makes it ideally suitable for machine bases and frames, linear slide systems, safety guarding and enclosures, worktables, structural framing and material handling. Use our configurator to build the right part for your application. The industrial aluminium profile system is the result of years of application experience and is characterised by extraordinary flexibility and proven reliability. The range includes construction profiles, functional profiles and heavy-duty profiles.

Slot Drain has been installed successfully in hundreds of applications, satisfying customers and construction professionals alike.

Slot Drain is designed for numerous market sectors. Slot Drain is made to suit your special requirements. Slot Drain provides drainage solutions that are durable, sanitary, aesthetically appealing, easy to clean, load class rated, corrosion and temperature resistant, ADA Compliant and odour eliminating.

Slot Profile System Software

Slot Profile System Free

Before Slot Drain, grating, trench drains and four-sloped floors were the standards.

Slot Drain changed surface drainage forever by providing the first pre-sloped, prefabricated drain system. The linear slot eliminates traditional grates that can be weak, trap bacteria and are difficult to clean. Slot Drain is applicable wherever floor or ground surfaces are subject to fluids, or have frequent cleaning requirements.

T-Slot / V-Slot

T-Slot has been around for many years. It has matured to a solid building system using in industry and by hobby engineers to build everything from machine enclosures to CNC machines, 3D printers and robots! It is strong enough to withstand many industrial stresses and modular enough allow for universal designs.

The T-slot system consists of extruded aluminum of various sizes with a “T” shaped slot on one or more of its sides. The shapes, sizes and designs may be different, but the “T” slot is common to all. The “T” slot allows of a variety of hardware to be connected to the extrusion so that complex structures can be constructed.

Slot Profile System Review

Types of T-Slot

There are many types of T-Slot available on the market. Some of the most common for small scale engineering include:

• V-Slot
• MakerBeam
• OpenBeam
• MicoRax

As show above, these 4 type range from 10mm to 20mm square profile. Each profile has its unique features, but all share the “T” slot function.

The profiles are not limited to square. V-slot, for example, comes in 4 sizes 20x80mm, 20x60mm, 20x40mm and 20x20mm :

Some manufactures produce larger square and other shaped profiles:

MakerBeam can fit a screw into its T-slot:

MicroRax is small, light and uses t-nuts and screws:

OpenBeam can fit a standard nut into its t-slot:

V-Slot uses t-nuts and is different from the other profiles because has “V” grooves that fit special “V” wheels and allow for easy linear motion:

Above are four different approaches to T-slot, there are in fact many more.
